Kratki Orbit Wood-burning Pedestal Stove

Kratki Orbit Wood-burning Pedestal Stove

0

1,395.00

A

Kratki Orbit 7KW / Wood-burning / External Air / Pedestal

The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.

Combustion of fuel thanks to the deflector.

Triple air system of combustion chamber: primary air – directed to the grate; secondary air supplied by the holes located in the back wall. Additionally, the system of air clean glass has been applied (curtain air). Moreover this air curtain is equipped with additinal lever to regulate it.

Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to lining of combustion chamber with TERMOTEC – heat accumulating material which raises the temperature in the combustion chamber.

Adjusting the external air inlet corresponding to the intensity of burning by using a single regulator, which is below the oven door.

— OR  —

— OR  —

— OR  —

SKU: HOS_4QL8P Categories: Tags:

Product Description

Kratki Orbit Features:

The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.

Combustion of fuel thanks to the deflector.

Triple air system of combustion chamber: primary air – directed to the grate; secondary air supplied by the holes located in the back wall. Additionally, the system of air clean glass has been applied (curtain air). Moreover this air curtain is equipped with additinal lever to regulate it.

Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to lining of combustion chamber with TERMOTEC – heat accumulating material which raises the temperature in the combustion chamber.

Adjusting the external air inlet corresponding to the intensity of burning by using a single regulator, which is below the oven door.



SAFETY AT ITS BEST

Perfect tightness thanks to the solid welds made in a noble gas shielding.

All steel elements are laser cut and bent on CNC bending machines.

Insert`s front equipped with a heat resistant ceramics that withstands temperatures up to 660°C.



CONVENIENCE

Movable grate and ashpan enables to clean the insert.

Reduced soot deposition through a system of pure glass (air curtain).

An elegant and comfortable handle.

It can be used in a various mounting conditions thanks to adjustable exhaust outlet: on the back or top of the stove (for back exhaust outlet installation purchase of top plate cover is required).



MODERN DESIGN

Improved vision of the fire thanks to the curved glass.

Modern cylindrical shape.

5 year warranty.

Technical figure

Technical data

Rated output (kW) 7
External air inlet Yes
Heating power range (kW) 5.5 – 9.0
Material stal
Heating efficiency (%) 76
Fuel type seasoned hardwood (moisture ≤20%)
Exhaust gas temperature (℃) 250
Max length of logs (cm) 25
Glazing type półokrągłe
Door opening system w lewo

Weight (kg) 99
Exhaust outlet diameter (mm) 150
Width (cm) 47.5
Height (cm) 91.4
Depth (cm) 57

BImSchV 2 compliance Yes

Klasa energetyczna A
Energy efficiency index (EEI) 100.18
CO emissions (at 13% O 2 ) ≤ given in % 0
Dust emission (mg/Nm3) 40

Combustion chamber lining Yes
Ash pan Yes
kW Output

Outside Air Kit

Fuel

EAN (GTIN)

5905033303515
